Mitsubishi FX3U-20SSC-H - Table Information Setting Items

10 Table Operation
10.1 Outline of Table Operation
191
FX3U-20SSC-H Positioning Block User's Manual
1
Introduction
2
System configuration
3
Example Connection
4
Installation
5
Wiring
6
Memory configuration and data
7
Before starting positioning control
8
Manual control
9
Positioning Control
10
Table Operation
10.1.3 Table information setting items
1. Setting items and contents
*1. Set a numeric value suitable for each operation to the operation information stored in the buffer
memory.
→ For set values and setting items in operation information, refer to the next page
*2. For details on the user units, refer to the following.
→ Refer to Section 7.10
*3. The m code is an auxiliary command to support positioning data in execution.
For details on m code, refer to the following.
→ Refer to Section 10.9
Setting item Content
Type of
table information
X-
axis
Y-
axis
XY-
axis
Operation
information
*1
Sets a positioning operation in the table operation along with a current address change, etc.
999
- No processing
-m code
-End
- 1-speed positioning
- Interrupt 1-speed constant quantity feed
- 2-speed positioning
- Interrupt 2-speed constant quantity feed
- Interrupt stop
- Multi-speed operation
(requires multiple tables)
- Linear interpolation
- Linear interpolation (interrupt stop)
- Circular interpolation
(center, CW direction)
- Circular interpolation
(center, CCW direction)
- Circular interpolation
(radius, CW direction)
- Circular interpolation
(radius, CCW direction)
- Mechanical zero return
- Current address change
- Absolute address specification
- Relative address specification
- Dwell
-Jump
Position
information
(x,y)
Sets the following items depending on the settings in the operation information.
• In positioning operations
Set the target address
Setting range: -2,147,483,648 to 2,147,483,647 (user unit)
*2
Set the value within -2,147,483,648 to 2,147,483,647PLS in converted pulse
data.
• In current address changes
Set the new current address.
Setting range: -2,147,483,648 to 2,147,483,647 (user unit)
*2
Set the value within -2,147,483,648 to 2,147,483,647PLS in converted pulse
data.
• In Dwell
Set a dwell time.
Setting range: 0 to 32767(
×10ms)
• In Jump
Set the jump No. table.
Setting range: 0 to 299
999
Speed
information
(fx,f,fy)
Set the operation speed.
Setting range: 1 to 50,000,000 (user unit)
*2
Set the value within 1 to 50,000,000Hz in converted pulse data.
999
Circle
information
(i,r,j)
Set the center coordinate and radius of the circle during circular interpolation operation.
Setting range: -2,147,483,648 to 2,147,483,647 (user unit)
*2
Set the value within -2,147,483,648 to 2,147,483,647PLS in converted pulse data.
--9
m code
information
*3
Sets m codes.
• No m code .................... -1
• After-mode m code.......0 to 9999
• With-mode m code .......10000 to 32767
999
