1 Introduction
1.3 Power and Status LED
19
FX3U-20SSC-H Positioning Block User's Manual
1
Introduction
2
System configuration
3
Exmample Connection
4
Installation
5
Wiring
6
Memory configuration and data
7
Before starting positioning control
8
Manual control
9
Positioning Control
10
Table Operation
1.3 Power and Status LED
LED display Color Status Description
POWER Green
OFF Power is not being supplied from the external power supply or the PLC
ON Power is being supplied from the external power supply or the PLC
X-READY
Y-READY
Green
OFF Error is occurring or positioning is being executed on the X/Y axis
ON Various operation commands are acceptable on the X/Y axis
X-ERROR
Y-ERROR
Red
OFF X/Y axis is operating normally
Flicker Error is occurring on the X/Y axis
ON CPU error is occurring on the X/Y axis
X-START
Y-START
Red
OFF Start input OFF
ON Start input ON
X-DOG
Y-DOG
Red
OFF DOG input OFF
ON DOG input ON
X-INT0
Y-INT0
X-INT1
Y-INT1
Red
OFF Interrupt input OFF
ON Interrupt input ON
X- φ A
Y- φ A
Red
OFF Manual pulse generator A-phase input OFF
ON Manual pulse generator A-phase input ON
X- φ B
Y- φ B
Red
OFF Manual pulse generator B-phase input OFF
ON Manual pulse generator B-phase input ON
