6.1.2 Data type and role
Note
• Positioning and servo parameters are automatically created and set for each of the X- and Y- axes
according to the factory default settings. (Leave default parameters for unused axes.)
• The table information is created for each of the X-, Y- and XY-axes.
• The positioning parameters, servo parameters and table information can be initialized, using
FX Configurator-FP or a sequence program.
→ For the initialization method using FX Configurator-FP, refer to Subsection 7.1.3 and
the FX Configurator-FP OPERATION MANUAL
→ For initialization using a sequence program, refer to Subsection 7.1.6 and 11.4.15
Data type Application
BFM number
X-axis Y-axis X-/Y-axis
Monitor data
Data indicating the control state.
The monitor data is stored in the buffer memory. Monitor the data
when necessary.
→ For details, refer to Section 11.3
BFM
#0 to #99
BFM
#100 to #199
-
Control data
The user controls the positioning control system, using the control
data.
The control data is related to operation-related settings, speed
change command during positioning operation, stop operation,
restart, etc.
→ For details, refer to Section 11.4
BFM
#500 to #599
BFM
#600 to #699
-
Positioning parameters
The positioning parameters specify the unit, speed and other
features of the positioning control.
Enter data according to the mechanical equipment and applicable
motor.
→ For details, refer to Section 11.1
BFM
#14000 to
#14199
BFM
#14200 to
#14399
-
Servo parameters
The servo parameters depend on the servo amplifier to be used, and
are used to control the servomotor.
Enter data according to the specifications to be used.
→ For details, refer to Section 11.2
BFM
#15000 to
#15199
BFM
#15200 to
#15399
-
Table information
The table information is used for table type positioning control.
Positioning control is based on the data specified in each table
(operation information, position information, speed information, m
code information).
Up to 300 positioning table points per table can be defined.
→ For details, refer to Section 11.5
BFM
#1000 to
#3999
BFM
#4000 to
#6999
BFM
#7000 to
#12999
