11 Buffer Memory (Parameters & Monitored Data)
11.3 Monitor Data
235
FX3U-20SSC-H Positioning Block User's Manual
11
Buffer Memory
12
Program Example
13
Diagnostics
A
List of Parameters and Data
B
Version Information
11.3.28 Regenerative load ratio [BFM #65, BFM #165]
The regenerative load ratio power to the maximum regenerative power is stored in percentage.
With regenerative brake option, the regenerative power ratio to the allowable capacity is stored.
11.3.29 Effective load torque [BFM #66, BFM #166]
The continuous effective load torque is stored.
This parameter stores the average value of the load ratio to the rated torque (100%) from the past 15
seconds.
11.3.30 Peak torque ratio [BFM #67, BFM #167]
The maximum torque during operations is stored.
This parameter stores the peak value to the rated torque (100%) from the past 15 seconds.
11.3.31 Servo warning code [BFM #68, BFM #168]
Warnings detected by the servo amplifier are stored.
Clear the cause of the warning.
→ For details on the warnings, refer to the manual of the connected servo amplifier
→ For details on the warning codes, refer to Subsection 13.2.4
11.3.32 Motor feedback position [BFM #71, #70, BFM #171, #170]
Motor feedback positions are stored.
BFM Number
Description Value Format Default
X-axis Y-axis
BFM #65 BFM #165 Regenerative load ratio (%) Decimal -
BFM Number
Description Value Format Default
X-axis Y-axis
BFM #66 BFM #166 Effective load torque (%) Decimal -
BFM Number
Description Value Format Default
X-axis Y-axis
BFM #67 BFM #167 Peak torque ratio (%) Decimal -
BFM Number
Description Value Format Default
X-axis Y-axis
BFM #71,#70 BFM #171,#170 Motor feedback position (PLS) Decimal -
