9 Positioning Control
9.2 1-speed Positioning Operation
153
FX3U-20SSC-H Positioning Block User's Manual
1
Introduction
2
System
configuration
3
Example
Connection
4
Installation
5
Wiring
6
Memory
configuration
and data
7
Before starting
positioning
control
8
Manual control
9
Positioning
Control
10
Table Operation
POINT
The positioning completion signal turns ON if the travel distance is 0.
If the travel distance is 0 or the travel time is too short, however, it is impossible for the sequence program to
detect the positioning completion signal turning OFF.
*1
*1. Turning OFF of the positioning completion signal can be detected when the positioning completion
signal output waiting time is set if the version is Ver.1.20 or later.
→ For details on the Positioning completion signal output waiting time, refer to Subsection 7.9.11
2. Operation Speed
The actual operation speed is "operation speed 1 × override setting."
Operation speed 1 can be changed using the operation speed change function except under the following
conditions.
→ For change of the operation speed, refer to Section 7.6
• During deceleration operation
• When the speed change disable during operation signal is ON.
3. Address Specification
The absolute/relative address can be specified.
With the specified absolute address: Specifies a target address (position) using address 0 as the base.
With the specified relative address: Specifies a travel distance from the current address.
4. Rotation Direction
With the specified absolute address: The rotation direction depends on whether the target address 1 is
larger or smaller than the current address.
With the specified relative address: The rotation direction is decided by the sign (positive/negative) of
target address 1.
BFM Number
Data type
X-axis Y-axis
Received target address (Ver.1.20 or later) BFM #25,#24 BFM #125,#124 Monitor data
Received target speed (Ver.1.20 or later) BFM #27,#26 BFM #127,#126 Monitor data
Current address (user) BFM #1,#0 BFM #101,#100 Monitor data
Current address (pulse) BFM #3,#2 BFM #103,#102 Monitor data
Real current address (User) (Ver.1.20 or later) BFM #21,#20 BFM #121,#120 Monitor data
Real current address (pulse) (Ver.1.20 or later) BFM #23,#22 BFM #123,#122 Monitor data
Operation speed present value BFM #11,#10 BFM #111,#110 Monitor data
System of units (user unit) Operation parameter 1 BFM #14000 b1,b0 BFM #14200 b1,b0 Positioning parameters
Unit of measurement for the
user units
Operation parameter 1 BFM #14000 b3,b2 BFM #14200 b3,b2 Positioning parameters
Position data magnification Operation parameter 1 BFM #14000 b5,b4 BFM #14200 b5,b4 Positioning parameters
Acceleration/deceleration
mode
Operation parameter 1 BFM #14000 b11 BFM #14200 b11 Positioning parameters
STOP mode Operation parameter 1 BFM #14000 b15 BFM #14200 b15 Positioning parameters
Servo end check enabled/
disabled
Operation parameter 2 BFM #14002 b0 BFM #14202 b0 Positioning parameters
Servo ready check enabled/
disabled
Operation parameter 2 BFM #14002 b1 BFM #14202 b1 Positioning parameters
Ring counter setting
(Ver.1.30 or later)
Operation parameter 2 BFM #14002 b3 BFM #14202 b3 Positioning parameters
Pulse rate BFM #14005,#14004 BFM #14205,#14204 Positioning parameters
Feed rate BFM #14007,#14006 BFM #14207,#14206 Positioning parameters
Maximum speed BFM #14009,#14008 BFM #14209,#14208 Positioning parameters
Acceleration time BFM #14018 BFM #14218 Positioning parameters
Deceleration time BFM #14020 BFM #14220 Positioning parameters
Servo end evaluation time BFM #14032 BFM #14232 Positioning parameters
Ring counter upper limit value (Ver. 1.10 or later) BFM #14101,#14100 BFM #14301,#14300 Positioning parameters
Positioning completion signal output waiting time
(Ver.1.20 or later)
BFM #14106 BFM #14306 Positioning parameters
Acceleration time 2 (Ver.1.30 or later) BFM #14108 BFM #14308 Positioning parameters
Deceleration time 2 (Ver.1.30 or later) BFM #14110 BFM #14310 Positioning parameters
To Next Page
