Mitsubishi S12A2 User Manual

No. 6(1/2)
INSPECTION RECORD SHEET
Minimum: 109.950 [4.3287]
Maximum: 110.050 [4.3327]
Limit
58.070
[2.2862]
Nominal
Approved by
6
b
Remark
a
S
A
Date
Checked by Measured by
mm[in.]Unit
Customer
Engine Model
Serial No.
Item
Connecting rod bushing inside diameter and connecting rod
big-end bore diameter - measure (1/2)
Direction
Measured value
Standard
58.020 to 58.040
[2.2842 to 2.2850]
110.000 to 110.022
[4.3307 to 4.3316]
Standard
Measuring
location
䃥110
[4.33]
B
䃥58
[2.28]
No.
1
A
Connecting rod bushing inside diameter
Connecting rod big-end bore diameter
Item
X
a
b
a
3
2
a
b
5
4
b
a
b
a
b
CY
Item to be measured
Connecting rod big end
bore diameter
Connecting rod bushing
inside diameter
