INSPECTION RECORD SHEET
No. 6(2/2)
Limit
58.070
[2.2862]
Minimum: 109.950 [4.3287]
Maximum: 110.050 [4.3327]
Item to be measured
Connecting rod big end
bore diameter
Connecting rod bushing
inside diameter
b
CY
11
10
b
a
b
a
a
9
a
b
8
7
A
Connecting rod bushing inside diameter
Connecting rod big-end bore diameter
Item
XB
a
b
Standard
58.020 to 58.040
[2.2842 to 2.2850]
Direction
䃥110
[4.33]
Nominal
Measured value
Standard
䃥58
[2.28]
No.
110.000 to 110.022
[4.3307 to 4.3316]
Unit
Customer
Engine Model
Serial No.
Measuring
location
Item
S
A
Date
Checked by Measured by
mm[in.]
Connecting rod bushing inside diameter and connecting rod
big-end bore diameter - measure (2/2)
Approved by
12
b
a
Remark
