No. 7(1/2䠅
INSPECTION RECORD SHEET
Remark
Measuring location
S
A
Customer
Engine Model
Date
Serial No.
Limit
Item
Rocker bushing inside diameter and rocker shaft outside
diameter - measure(1/2)
Unit
Standard
mm[in.]
Standard
No.
Direction
Rocker shaft outside diameter
XYX
Rocker bushing
inside diameter
Nominal
Item to be measured
Minimum
䃥32
[1.26]
31.950
[1.2614]
䃥32
[1.26]
32.100
[1.2638]
31.975 to 31.991
[1.2589 to 1.2595]
32.055 to 32.080
[1.2620 to 1.2630]
ClearanceItem
Rocker bushing inside diameter
Y Maximum
Approved by Checked by Measured by
1
a
b
3
b
a
4
b
a
b
6
5
b
a
a
Rocker shaft
outside diameter
Measured value
2
b
a
