USB Audio Interface Module Specifications
Before you mount and install the USB Audio Interface Module (USB AIM), verify that you meet the
environmental requirements necessary for the device to operate.
Table 18: USB Audio Interface Module Specifications
USB Audio Interface Module Feature Specifications
Physical dimensions Height (excluding the rubber foot): 1.65 inches
(42 mm)
Width: 8.39 inches (213 mm)
Depth: 5.23 inches (133 mm)
Weight 1.43 lb (0.65 kg)
AC Operating Voltage for the USB AIM Power
Supply
90 VAC - 264 VAC
Minimum input voltage 90 VAC with 57 Hz~63
Hz
Maximum input voltage 264 VAC with 47 Hz~53
Hz
Typical input voltages are 115 VAC and 230
VAC
DC Operating Voltage for the USB AIM Device 12 VDC (nominal)
Maximum Power Consumption 0.5 A at 12 VDC (6 W)
Operating Temperature 5 °C (41 °F) — 40 °C (104 °F)
Storage Temperature -25 °C (-13 °F) — 70 °C (158 °F)
Relative Humidity Operating 0% — 90% relative humidity at 40 °C non-con-
densing
USB Audio Interface Module FRU/FRE Information
If you cannot resolve your issues with the USB Audio Interface Module (USB AIM) (B1941) by
performing basic diagnostics and troubleshooting, replace the item.
The following table provides information about the Field Replaceable Units (FRUs) and Field
Replaceable Entities (FREs) for the USB AIM.
Table 19: USB AIM FRU/FRE Information
Part Number Description
PMPN4052A USB Audio Interface Module Interchangeable
Power Supply without Adaptor (1 piece)
RLN6349A North American Power Adaptor (1 piece)
RLN6234A European Power Adaptor (1 piece)
1564027V01 UK Power Adaptor (1 piece)
58012005001 Australia Power Adaptor (1 piece)
RLN6448A Brazil Power Adaptor (1 piece)
PMHN4249A Mounting Bracket Kit
Table continued…
MN000672A01-E
Chapter 4: USB Audio Interface Module
