USB AIM Tab
The USB AIM tab contains a list of Motorola peripherals that can be connected to the USB Audio
Interface Module (USB AIM) device. The list is visible only when the USB AIM device is connected to
the MCC 7100 IP Dispatch Console. When the device is connected to the console computer, all the
Motorola peripherals are listed, whether they are connected to the USB AIM or not. By using the USB
AIM tab, you can map or unmap the peripherals.
Mapping and Unmapping Motorola Peripherals
Perform this procedure to map or unmap the peripherals connected to the USB Audio Interface Module
device (USB AIM).
Prerequisites: Connect the USB AIM to the MCC 7100 IP Dispatch Console computer.
Procedure:
1 From the Windows Start menu, select All Programs → Motorola → MCC 7100 Dispatch →
Peripheral Configuration Tool.
2
Map the peripherals by performing one of the following actions:
If… Then…
If you want to map all
the Motorola peripheral
devices,
click Configure AIM.
If you want to map or
unmap a single Motor-
ola peripheral device,
perform the following actions:
a Select the USB AIM tab.
b For the peripheral that you want to map or unmap, perform
one of the following actions:
•
To map a peripheral device, go to the drop-down list next
to the device and select it from the list.
• To unmap a peripheral device, go to the drop-down list
next to the device and select the blank selection.
MN000672A01-E
Chapter 5: Console Dispatch Status and Peripheral Configuration Tool
132 Send Feedback
