7000 Console Proxy is referring to the IP address of the server assigned in the Customer Enterprise
Network (CEN) and not the ASTRO
®
25 RNI configured IP address.
Procedure:
1 From the Windows Start menu, select All Programs → Motorola → MCC 7100 Dispatch →
Console Status.
2 Select the Proxy Server List tab.
3 Click Add to create a proxy server entry.
4 In the Host IP field, enter the <hostname> or <IP address> for the PRX 7000 server.
NOTICE: When using an IP address, use the NAT’d IP address of the CEN for the PRX
7000 Console Proxy. The proxy server is only included if a proxy is configured by
hostname in the Console Dispatch Status application.
5 Enter a text string to uniquely identify each proxy server entry.
Step example: Site 55 Server
6 Click Save.
Setting Up the Domain for an MCC 7100 IP Dispatch Console Inside the
ASTRO Radio Network Infrastructure
After you configure the IP and Domain Name Service (DNS) information of the dispatch console, add
the MCC 7100 IP Dispatch Console to the console site Active Directory domain.
NOTICE: This procedure is not applicable for ASTRO
®
25 Conventional System (K core).
Prerequisites: Configure the DNS server IP addresses and DNS suffixes. See Configuring the
Network Interface Card for an MCC 7100 IP Dispatch Console Inside the ASTRO RNI on page 51.
IMPORTANT: Apply a secure password to the Administrator account at this time. Failure to do
so may result in a security breach. Follow standard Microsoft procedures to change the
password on this account.
NOTICE: A domain administrator account and password associated with this domain account
are required to join the Active Directory domain. For additional domain authentication
information, see the Authentication Services manual.
Procedure:
1 In the Windows operating system, navigate to <systemdrive>\Program Files (x86)\Motorola
\AAA\bin
2 Double-click JoinADomain.exe.
NOTICE: If the Active Domain (AD) cannot be found, manually enter the domain name.
3 If the User Account Control window appears, click Yes.
4 In the Join Active Directory Domain window, enter the <user name> and <password> for
the domain account used to join the Windows-based device to the active directory domain.
The Organization Unit (OU) selection gets updated.
5 From the Organization Unit (OU) drop-down list, select the relevant organization unit.
The basic OUs are:
•
Windows 7 MCC 7100 IP Consoles
MN000672A01-E
Chapter 2: MCC 7100 IP Dispatch Console Setup and Installation
66 Send Feedback
