If… Then…
If you want to unmap a
Motorola peripheral,
a Select the USB AIM tab.
b From the drop-down list next to the device that you want
unmap, select the blank selection.
If you want to replace
the Motorola headset 1
with a non-Motorola pe-
ripheral,
a Select the Audio Outputs tab.
b From the drop-down list next to the device that you want to
configure as your headset speaker, select Headset 1
Speaker.
c Select the Audio Inputs tab.
d From the drop-down list next to the device that you want to
configure as your headset microphone, select Headset 1
Microphone.
e Select the PTT/Monitor tab.
f From the drop-down list next to the device that you want to
configure as your headset Push-to-Talk (PTT), select
Headset 1 PTT.
If you want to replace
the Motorola desktop
microphone with a non-
Motorola peripheral,
a Select the Audio Inputs tab.
b From the drop-down list next to the device that you want
map as your desktop microphone, select Desktop Micro-
phone.
If you want to replace
the Motorola footswitch
with a non-Motorola pe-
ripheral,
a Select the PTT/Monitor tab.
b From the drop-down list next to the device that you want
map as your footswitch, select Footswitch.
2 Save the profile:
• To save the changes to the existing profile, select Apply.
• To save the changes as a new profile, select Save As.
3 Close the Peripheral Configuration Tool by clicking OK.
Deleting a Profile
Perform this procedure to selectively choose which profiles to remove from the tool, or delete all
profiles except for the currently active profile that does not appear in the list of profiles to delete.
Procedure:
1 From the Windows Start menu, select All Programs → Motorola → MCC 7100 Dispatch →
Peripheral Configuration Tool.
2 In the Profile pane, click Delete.
3 In the Select Profile(s) to Delete window, perform one of the following actions:
• To remove all the profiles except for the currently active profile, select the Select All check
box.
• To remove a single profile, select the check box next to it.
4 Click Delete.
5 Confirm the deletion by clicking OK.
MN000672A01-E
Chapter 5: Console Dispatch Status and Peripheral Configuration Tool
136 Send Feedback
