Motorola MC68HC908AB32 User Manual

Clock Generator Module (CGM)
CGM Registers
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA Clock Generator Module (CGM) 147
AUTO — Automatic Bandwidth Control Bit
This read/write bit selects automatic or manual bandwidth control.
When initializing the PLL for manual operation (AUTO = 0), the ACQ
bit should be cleared before turning the PLL on. Reset clears the
AUTO bit.
1 = Automatic bandwidth control
0 = Manual bandwidth control
LOCK — Lock Indicator Bit
When the AUTO bit is set, LOCK is a read-only bit that becomes set
when the VCO clock CGMVCLK, is locked (running at the
programmed frequency). When the AUTO bit is clear, LOCK reads as
0 and has no meaning. Reset clears the LOCK bit.
1 = VCO frequency correct or locked
0 = VCO frequency incorrect or unlocked
ACQ
— Acquisition Mode Bit
When the AUTO bit is set, ACQ
is a read-only bit that indicates
whether the PLL is in acquisition mode or tracking mode. When the
AUTO bit is clear, ACQ
is a read/write bit that controls whether the
PLL is in acquisition or tracking mode.
In automatic bandwidth control mode (AUTO = 1), the last-written
value from manual operation is stored in a temporary location and is
recovered when manual operation resumes. Reset clears this bit,
enabling acquisition mode.
1 = Tracking mode
0 = Acquisition mode
XLD — Crystal Loss Detect Bit
When the VCO output, CGMVCLK, is driving CGMOUT, this
read/write bit indicates whether the crystal reference frequency is
active or not. To check the status of the crystal reference, the
following procedure should be followed:
1. Write a 1 to XLD.
2. Wait 4 × N cycles. (N is the VCO frequency multiplier.)
3. Read XLD.
1 = Crystal reference is not active
0 = Crystal reference is active
