Motorola MC68HC908AB32 - TIMB Channel 1 Register High (TBCH1 H)

Timer Interface Module B (TIMB)
I/O Registers
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA Timer Interface Module B (TIMB) 219
Address: $0049
Bit 7 654321Bit 0
Read:
Bit 15 14 13 12 11 10 9 Bit 8
Write:
Reset: Indeterminate after reset
Figure 12-16. TIMB Channel 1 Register High (TBCH1H)
Address: $004A
Bit 7 654321Bit 0
Read:
Bit 7 654321Bit 0
Write:
Reset: Indeterminate after reset
Figure 12-17. TIMB Channel 1 Register Low (TBCH1L)
Address: $0033
Bit 7 654321Bit 0
Read:
Bit 15 14 13 12 11 10 9 Bit 8
Write:
Reset: Indeterminate after reset
Figure 12-18. TIMB Channel 2 Register High (TBCH2H)
Address: $0034
Bit 7 654321Bit 0
Read:
Bit 7 654321Bit 0
Write:
Reset: Indeterminate after reset
Figure 12-19. TIMB Channel 2 Register Low (TBCH2L)
