Motorola MC68HC908AB32 User Manual

Serial Communications Interface Module (SCI)
I/O Registers
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA Serial Communications Interface Module (SCI) 265
• Enables the transmitter
• Enables the receiver
• Enables SCI wakeup
• Transmits SCI break characters
SCTIE — SCI Transmit Interrupt Enable Bit
This read/write bit enables the SCTE bit to generate SCI transmitter
CPU interrupt requests. Reset clears the SCTIE bit.
1 = SCTE enabled to generate CPU interrupt
0 = SCTE not enabled to generate CPU interrupt
TCIE — Transmission Complete Interrupt Enable Bit
This read/write bit enables the TC bit to generate SCI transmitter CPU
interrupt requests. Reset clears the TCIE bit.
1 = TC enabled to generate CPU interrupt requests
0 = TC not enabled to generate CPU interrupt requests
SCRIE — SCI Receive Interrupt Enable Bit
This read/write bit enables the SCRF bit to generate SCI receiver
CPU interrupt requests. Reset clears the SCRIE bit.
1 = SCRF enabled to generate CPU interrupt
0 = SCRF not enabled to generate CPU interrupt
ILIE — Idle Line Interrupt Enable Bit
This read/write bit enables the IDLE bit to generate SCI receiver CPU
interrupt requests. Reset clears the ILIE bit.
1 = IDLE enabled to generate CPU interrupt requests
0 = IDLE not enabled to generate CPU interrupt requests
Address: $0014
Bit 7 654321Bit 0
Read:
SCTIE TCIE SCRIE ILIE TE RE RWU SBK
Write:
Reset: 00000000
Figure 15-10. SCI Control Register 2 (SCC2)
