FLASH Memory
Wait Mode
MC68HC908AB32 — Rev. 1.0 Technical Data
MOTOROLA FLASH Memory 67
Examples of protect start address:
4.9 Wait Mode
Putting the MCU into wait mode while the FLASH is in read mode does
not affect the operation of the FLASH memory directly, but there will not
be any memory activity since the CPU is inactive.
The WAIT instruction should not be executed while performing a
program or erase operation on the FLASH, otherwise the operation will
discontinue, and the FLASH will be on Standby Mode.
4.10 Stop Mode
Putting the MCU into stop mode while the FLASH is in read mode does
not affect the operation of the FLASH memory directly, but there will not
be any memory activity since the CPU is inactive.
The STOP instruction should not be executed while performing a
program or erase operation on the FLASH, otherwise the operation will
discontinue, and the FLASH will be on Standby Mode
NOTE:
Standby Mode is the power saving mode of the FLASH module in which
all internal control signals to the FLASH are inactive and the current
consumption of the FLASH is at a minimum.
BPR[7:0] Start of Address of Protect Range
$00 The entire FLASH memory is protected.
$01 (0000 0001) $8080 (1000 0000 1000 0000)
$02 (0000 0010) $8100 (1000 0001 0000 0000)
and so on...
$FE (1111 1110) $FF00 (1111 1111 0000 0000)
$FF The entire FLASH memory is not protected.
Note:
The end address of the protected range is always $FFFF.
