Motorola MC68HC908AB32 User Manual

Memory Map
Technical Data MC68HC908AB32 — Rev. 1.0
44 Memory Map MOTOROLA
$FE09
↓
$FE0B
Reserved
3 Bytes
$FE0C Break Address Register High (BRKH)
$FE0D Break Address Register Low (BRKL)
$FE0E Break Status and Control Register (BRKSCR)
$FE0F LVI Status Register (LVISR)
$FE10 EEPROM Divider Non-volatile Register High (EEDIVHNVR)
$FE11 EEPROM Divider Non-volatile Register Low (EEDIVLNVR)
$FE12
↓
$FE19
Reserved
8 Bytes
$FE1A EEPROM Timebase Divider Register High (EEDIVH)
$FE1B EEPROM Timebase Divider Register Low (EEDIVL)
$FE1C EEPROM Non-volatile Register (EENVR)
$FE1D EEPROM Control Register (EECR)
$FE1E Reserved
$FE1F EEPROM Array Configuration Register (EEACR)
$FE20
Monitor ROM
307 Bytes
↓
$FF52
$FF53
Unimplemented
43 Bytes
↓
$FF7D
$FF7E FLASH Block Protect Register (FLBPR)
$FF7F
Unimplemented
65 Bytes
↓
$FFBF
$FFC0
Reserved FLASH Memory
16 Bytes
Reserved for Compatibility with HC08AB16/24/32
↓
$FFCF
$FFD0
FLASH Vectors
48 Bytes
↓
$FFFF
Figure 2-1. Memory Map (Continued)
