Accessories 2 - 15
5. Use the TPC/IP Settings tab to modify the DNS and WINS identification settings of the cradle.
Figure 2-11
Cradle Settings Window - TCP/IP Settings Tab
6. Use the Port Settings tab to modify the USB port settings of the cradle.
Table 2-5
Cradle Settings - General Settings Fields
Field Description
Device Name A text string used to describe the MobileDox device. Any 15-character string may
be entered.
Custom String A text string for any desired usage (examples are: location, asset ID, etc.). Any
15-character string may be entered.
Require Admin Privileges to
Modify Settings check box
Selecting this check box requires users to have administrative privileges in order
to modify MobileDox settings. Administrative privileges are validated using
standard Windows authentication.
Table 2-6
Cradle Settings - TCP/IP Settings Fields
Field Description
Use DHCP If check box is selected, necessary information is retrieved from the DHCP server.
If check box is not selected, static configuration is used (information needs to be
entered).
IP Address The IP address that the MobileDox uses when communicating on the network.
Subnet Mask The subnet mask that the MobileDox uses when communicating on the network.
Gateway Address The IP address that the MobileDox uses to send non-local IP network data.
DNS Address The IP address of a server(s) that can resolve Internet names into IP addresses.
WINS Address The IP address of a server(s) that can resolve Windows network names into IP
addresses. This field must be populated correctly when using ActiveSync.
