Application Deployment for Windows CE 5 - 11
Figure 5-6
Download Complete Screen
5. On completion, press ENTER to return to the Bootloader menu to select the next file to download.
6. To exit Bootloader, select Exit from the Bootloader main screen and press ENTER.
Loading Files via USB
Use Bootloader to download customized flash file system partitions to the MC9190-G and load hex files to the flash
memory of the MC9190-G.
To load the hex files on to the MC9190-G using USB:
1. Download the WCE USBDownload application from the Support Central web site. Follow the installation
instructions with the application.
2. Connect the MC9190-G to a host computer using the Single Slot Serial/USB Cradle or USB Cradle Cable.
3. On the host computer, launch the WCE USBDownload application.
Figure 5-7
USB Download Window
4. Press the primary battery release to partially eject the battery from the MC9190-G.
5. Press and hold the trigger and then press and release the Power button.
6. Continue to hold the trigger and push the battery back into the MC9190-G.
7. When the Bootloader screen appears, release the trigger.
Splash screen
############# 100%
Download complete
in - 0.042 seconds
(1854142 bytes/second)
Hit Enter to Acknowledge -
