To maintain good control of this axis the
damping effect should be reduced
proportionally with stick travel. The
reduction level is configured by
selecting a setting between 0 and 200%
for the Suppression parameter.
The servo pulse of the gyro channel
covers the entire setting range.
modes by changing the prefix for the
sensitivity setting.
The gyro operates in Damping mode (as
described in the opposite column) if the
sensitivity setting is a positive value.
In Heading-hold mode the control signal
for the axis to be stabilised is used as
the setting for the rotational speed
around this axis. In neutral position the
rotational speed is maintained at zero:
The model always points in the same
direction.
The sensitivity setting ranges from
0% ... 100%:
The sensitivity setting ranges from
-100% ... +100%:
Fixval.Sense
With this parameter, a fixed gyro sensitivity is set for each flight phase individually.
Alternatively, a control can be used. If this is preferred, set the sensitivity to OFF
and assign a control to the Gyro control function. Refer to page 104 for more
details regarding controls assignment.
o The following applies to pure Damping gyros: Setting range: 0% to +100%
o The following applies to Heading gyros:
Setting range for heading-hold: -100% to -1%
Setting range for damping: 0% to +100%
Only the value of the activated flight phase can be displayed. When implementing
changes make sure to activate the desired flight phase first.
Damping
+100%
-100%
Heading
OFF
(assigned control)
