percentage figure at the selected calibration point.
With one hand you can easily and conveniently measure and check the control
surface travel (ruler, calliper), while the other hand remains free to change the
value using the wheel.
4. If the travel is correct, press the allocation button F.
The servo(s) assume(s) the position corresponding to the position of the
associated control.
Vertical line for orientation:
The vertical dotted line in the graph shows the current position of the associated
control for easier orientation. If you activate a value using the allocation button F,
the vertical line jumps to the corresponding point and remains there until you press
the allocation button again or operate the associated control.
