Multiplex Profi TX - Page 77

Model templates
Seite 74
PROFI TX
Switch-3
e
Mixture
i
---
-
-
Aux-3
---
Slow
Fixed value
FP4
0.0s
OFF
Aux-4
---
Slow
Fixed value
FP4
0.0s
OFF
Collective
same as Throttle
Slow
Fixed value
FP4
0.0s
OFF
Thr.Limiter
F>
Slow
Fixed value
FP4
0.0s
OFF
FP4
= 4 flight phases
i
= I.C. engine
e
= electric motor
All the helicopter templates contain the same set of mixers:
 four freely configurable, flight phase-enabled control mixers;
e.g. to mix Aileron, Elevator, Rudder in Throttle.
 Tail rotor mixer up to 4 servos
 Main rotor mixer
Name
Mixer inputs
Settings
Value
TAIL ROTOR
Rudder, Collective
Offset
Coll.+/-
Coll. origin
Rudd.Diff.
OFF
OFF
0%
OFF
MAINROTOR-R.
Rudder, Elevator,
Collective
Geometry
Rotation
Lever +/-
90%
0°
0%
MAINROTOR-L.
Rudder, Elevator,
Collective
MAINROTOR-FB
Rudder, Elevator,
Collective
MAINROTOR-4
Rudder, Elevator,
Collective
