Chapter 5: Programming 5-75
Interleaved 2 of 5 Overlap
25646
Selection Programming Tag Sequence
Programming Mode, Hex 6, Hex B, Hex B, Hex 3, Save and Reset3 overlaps
4 overlaps Programming Mode, Hex 6, Hex B, Hex B, Hex 4, Save and Reset
1 overlap Programming Mode, Hex 6, Hex B, Hex B, Hex 1, Save and Reset
2 overlaps Programming Mode, Hex 6, Hex B, Hex B, Hex 2, Save and Reset
Setting
Default
Note: This is an Advanced Programming Feature and should only be done under
the recommendation and direction of NCR; otherwise, unexpected results
may occur.
Interleaved 2 of 5 Minimum Segment Size
Selection Programming Tag Sequence
Programming Mode, Hex 6, Hex B, Hex E, Hex 4, Save and Reset
Programming Mode, Hex 6, Hex B, Hex E, Hex 5, Save and Reset
2 segment size Programming Mode, Hex 6, Hex B, Hex E, Hex 2, Save and Reset
Programming Mode, Hex 6, Hex B, Hex E, Hex 3, Save and Reset
Programming Mode, Hex 6, Hex B, Hex E, Hex 6, Save and Reset
Programming Mode, Hex 6, Hex B, Hex E, Hex 7, Save and Reset
25647
Programming Mode, Hex 6, Hex B, Hex E, Hex 8, Save and Reset
Programming Mode, Hex 6, Hex B, Hex E, Hex 9, Save and Reset
Note: This is an Advanced Programming Feature and should only be done under the
recommendation and direction of NCR; otherwise, unexpected results may occur.
3 segment size
4 segment size
5 segment size
6 segment size
7 segment size
8 segment size
9 segment size
Setting
Default
Enable/Disable Interleaved 2 of 5 Partials
27060
Selection Programming Tag Sequence
Programming Mode, Hex 6, Hex C, Hex D, Save and Reset
Disable Programming Mode, Hex 6, Hex C, Hex C, Save and Reset
Enable
Setting
Default
Note: This is an Advanced Programming Feature and should only be done under
the recommendation and direction of NCR; otherwise, unexpected results
may occur.
