5-14 Chapter 5: Programming
Program Entry Procedure (Shortcut Method)
The following example is a typical program entry procedure.
1. Disconnect scanner from the host terminal.
2. Apply power to the 7893 (or scan the Reset tag).
3. Scan the Program Mode tag.
4. Scan the two Hex tags corresponding to the worksheet number.
5. Scan specific parameter tag (Hex A–F).
6. Scan appropriate Hex tags to enter parameters.
7. Repeat steps 4 thru 6 until all the parameters are entered.
8. Scan the Save and Reset tag. All parameter changes are saved and 7893 is reset (goes
through initial power–up sequence). The 7893 now operates using the new program.
Parameter Defaults
Programming Mode Program Parameters Default Setting
Communications
Protocol
Protocol
No default value—
remains as
programmed
Tone On/Off On
Tone Frequency 2232 Hertz
Tone Length 45 ms
Tone Volume 2
Good Read Tone
Not–On–File Volume 0
Lockout Time 450 Milliseconds
Restart Lockout Timer On
Active Time 15 Minutes
Timers
900ms Lockout Timer Restart Limit Off
