NCR RealPOS User Manual

Chapter 5: Programming 5-21
Note: Two programming tags must be scanned to enable this parameter: Hex E followed by
Hex 0.
RS-232
RS-232 is used to connect the 7893 to almost any RS-232 type of communications device. This
protocol uses 7-bit ASCII by default to send tag data to the device.
Good Read Tone
Tone On/Off
A
Off
0
On
Tone
Frequency
(Hertz)
Tone
Volume
Tone
Length
(Milliseconds)
Not-On-File
Tone Volume
When entering Tone Frequency, the adjustment can be
incremented upward by scanning the
Hex B
tag. Each time
you scan the
Hex B
, the tone frequency increases one unit.
Scan the
End
tag or a valid Hex tag to end this mode.
When entering Tone Length, the adjustment can be
incremented upward by scanning the
Hex C
tag. Each time
you scan the
Hex C
tag, the tone length increases one unit.
Scan the
End
tag or a valid Hex tag to end this mode.
When entering Tone Volume, the adjustment can be
incremented upward by scanning the
Hex D
tag. Each time
you scan the
Hex D
tag, the tone length increases one unit.
Scan the
End
tag or a valid Hex tag to end this mode.
When entering Not-On-File Tone Volume, the adjustment can be
incremented upward by scanning the
Hex E
tag. Each time you scan
the
Hex E
tag, the tone length increases one unit.
Scan the
End
tag or a valid Hex tag to end this mode.
B
C
D
C
D
EE
1
B
22761
Your Program
Good Read Tone
1 1
Protocol
The Good Read Tone programming mode selects the parameters for sounding a tone each time
the 7893 successfully reads a bar code. It also controls the volume of the Not-On-File tone.
This mode contains five shortcuts: A, B, C, D, and E. After entering this programming mode,
proceed directly to a specific parameter by scanning the appropriate shortcut Hex tag. This
eliminates the need to enter all parameters when only one needs changing. R
Tone On/Off
The Hex A tag selects the Tone On/Off programming parameter, which offers two options, On
and Off. The Hex 0 tag turns the Good Read Tone off and the Hex 1 tag turns the Good Read
Tone on.
