FEATURE DESCRIPTION
Fiber Port
1G/10GBASE-X
Connects to an SFP adapter
and fiber cable for network
testing. NOTE: 100FX SFPs
are not supported.
RJ-45 LAN Port
10M/100M/1G/
2.5G/5G/10G-
BASE-T
Connects to a copper
Ethernet cable for network
testing
Supports PoE (with com-
patible unit hardware)
Transmit LEDs
Green LED lit: Linked
Yellow LED flashing: Activity
USB Type-A Port
Connects to any USB device
RJ-45 Cable Test
and Management
Port
Connects to an Ethernet
cable for patch cable testing
and unit management
USB Type-C
On-the-Go Port
Connects to a USB Type-C
connector for file transfer
and to the included AC
adapter for charging the unit
Microphone
Allows voice input
Flash
Acts as a flashlight
Micro SD Card Slot
Used for removable storage
expansion (See Inserting a
Micro SD Card below.)
Volume Buttons
Increase or decrease the
audio volume
Introduction
25
