4. In the Server Address field, enter smb://readyshare.
5. Click the Connect button.
6. When prompted, select the Guest radio button.
7. If you set up access control on the router and you allowed your Mac to access the network, select the
Registered User radio button and enter admin for the name and password for the password.
For more information about access control, see Allow or Block Access to Your Network on page 104.
8. Click the Connect button.
A window displays the files and folders on the device.
Map a USB Device to a Windows Network Drive
To map the USB device to a Windows network drive:
1. Connect a USB storage device to the modem router’s USB port.
If your storage device uses a power supply, you must use it when you connect the device to the router.
When you connect the storage device to the modem router’s port, it might take up to two minutes before
it is ready for sharing. By default, the device is available to all computers on your local area network
(LAN).
2. Select Start > Run.
3. Enter \\readyshare in the dialog box.
4. Click the OK button.
A window automatically opens and displays the USB device.
5. Right-click the USB device and select Map network drive.
The Map Network Drive window opens.
6. Select the drive letter to map to the new network folder.
7. Click the Finish button.
The USB device is mapped to the drive letter that you specified.
Back Up Windows Computers With ReadySHARE Vault
Your modem router comes with free backup software for all the Windows computers in your home. Connect
a USB hard disk drive (HDD) to the modem router for centralized, continuous, and automatic backup.
The following operating systems support ReadySHARE Vault:
• Windows 7
• Windows 8
• Windows 8.1
• Windows 10
Share a Storage Device Attached to the Modem Router
138
AC1200 WiFi VDSL/ADSL Modem Router Model D6220
