(Continued)
DescriptionField or Column
The downstream and upstream signal-to-noise ratio margin (SNRM) in dB. The
SNRM expresses the signal quality in relation to interference.
Noise Margin
The interval at which the statistics are updated on this page.Poll Interval
Change the Traffic Statistics Polling Frequency
You can change the polling frequency or stop traffic polling.
To change the traffic statistics polling frequency or stop polling:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > ADVANCED Home.
The ADVANCED Home page displays.
5. In the Internet Port pane, click the Show Statistics button.
A pop-up window displays.
6. Change the polling frequency or stop polling:
• To change the polling frequency, do the following:
a. In the Poll Interval field, enter a time in seconds.
b. Click the Set Interval button.
• To stop polling, click the Stop button.
View, Renew, or Release the TCP/IP Internet Connection
You can view information about a TCP/IP Internet connection of the modem router and renew or release
such a connection.This information displays only if the modem router connects to the ISP network over a
TCP/IP connection. Such a connection usually functions over an Ethernet WAN connection.
Manage the Modem Router and Monitor the Traffic
207
AC1200 WiFi VDSL/ADSL Modem Router Model D6220
