The modem router emails the logs to the address that you specified (see Set Up Security Event Email
Notifications on page 120).
Specify Which Activities Are Logged
You can specify which activities are logged.These activities display in the log and are forwarded to the
syslog server if you enabled the syslog server function.
To manage which activities are logged:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Administration > Logs.
The Logs page displays.
5. Select the check boxes that correspond to the activities that you want to be logged.
By default, all check boxes are selected.
6. Clear the check boxes that correspond to the activities that you do not want to be logged.
7. Click the Apply button.
Your settings are saved.
Monitor and Meter Internet Traffic
Traffic metering allows you to monitor the volume of Internet traffic that passes through the modem router
Internet port. With the traffic meter utility, you can set limits for traffic volume, set a monthly limit, and get a
live update of traffic usage.
Start the Traffic Meter Without Traffic Volume Restrictions
You can monitor the traffic volume without setting a limit.
To start or restart the traffic meter without configuring traffic volume restrictions:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
Manage the Modem Router and Monitor the Traffic
212
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

Table of Contents

Other manuals for NETGEAR D6220

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR D6220 and is the answer not in the manual?

NETGEAR D6220 Specifications

General IconGeneral
DSL WAN-
Ethernet WANYes
SIM card slotNo
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)900 Mbit/s
Product typeTabletop router
Product colorBlack
Security algorithmsWPA, WPA2, WPA2-PSK
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11ac
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
USB 2.0 ports quantity1
Ethernet LAN (RJ-45) ports5
Power source typeAC
Routing protocolsIP
Antennas quantity2
Cables includedLAN (RJ-45), Phone (RJ-11)
Weight and Dimensions IconWeight and Dimensions
Depth182 mm
Width240 mm
Height41 mm
Weight341 g
