NETGEAR D6220 User Manual

these settings if you need a specific IP subnet that one or more devices on the network use, or if competing
subnets use the same IP scheme.
To change the LAN IP address settings:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Setup > LAN Setup.
5. In the IP Address field, enter the LAN IP address for the modem router.
6. In the IP Subnet Mask, enter the LAN subnet mask for the modem router.
7. Click the Apply button.
Your settings are saved.
If you changed the LAN IP address of the modem router, you are disconnected when the changes take
effect.
To reconnect, close your browser, relaunch it, and log in to the modem router at its new LAN IP address.
Manage the Router Information Protocol Settings
Router Information Protocol (RIP) lets the modem router exchange routing information with other routers.
By default, RIP is enabled in both directions (in and out) without a particular RIP version.
Manage the WAN and LAN Network Settings
183
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

NETGEAR D6220 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Security algorithms	WPA, WPA2, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Routing protocols	IP
Antennas quantity	2
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	182 mm
Width	240 mm
Height	41 mm
Weight	341 g
