NETGEAR D6220 User Manual

Select one of the following radio buttons and configure the options accordingly:
• To allow access from a single IP address on the Internet, select the Only This Computer radio
button. Enter the IP address to be allowed access.
• To allow access from a range of IP addresses on the Internet, select the IP Address Range radio
button. Enter a beginning and ending IP address to define the allowed range.
• To allow access from any IP address on the Internet, select the Everyone radio button.This radio
button is selected by default.
7. Specify the port number for accessing the modem router’s web pages.
The default is 8443, which is a common alternate for HTTPS. For greater security, enter a custom port
number for accessing the modem router’s web pages remotely. Choose a number from 1024 to 65535,
but do not use the number of any common service port.
8. Click the Apply button.
Your settings are saved.
Use the Modem Router as a DSL Modem Only
By default, the modem router functions as both a modem and a router.You can change the operation mode
to a mode in which the modem router functions as a DSL modem only with the routing, firewall, WiFi, and
traffic meter features disabled.
A typical use of such a mode is when the modem router is used only for DSL connectivity behind a router,
firewall, or security device manager that provides routing, firewall, WiFi, and traffic meter features.
To configure the modem router as a DSL modem only:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > Device Mode.
The Device Mode page displays.
5. From the Device Mode menu, select Modem (Modem Only).
6. Click the Apply button.
Your settings are saved. The modem router restarts.
Manage the Modem Router and Monitor the Traffic
219
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

NETGEAR D6220 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Security algorithms	WPA, WPA2, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Routing protocols	IP
Antennas quantity	2
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	182 mm
Width	240 mm
Height	41 mm
Weight	341 g
