Set Up an IPv6 PPPoE Internet Connection
To set up a PPPoE IPv6 Internet connection:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > IPv6.
The Basic Settings page displays.
5. From the Internet Connection Type menu, select PPPoE.
The modem router automatically detects the information in the following fields:
• Router’s IPv6 Address on WAN.This field shows the IPv6 address that is acquired for the modem
router’s WAN (or Internet) interface.The number after the slash (/) is the length of the prefix, which
is also indicated by the underline (_) under the IPv6 address. If no address is acquired, the field
displays Not Available.
• Router’s IPv6 Address on LAN.This field shows the IPv6 address that is acquired for the modem
router’s LAN interface.The number after the slash (/) is the length of the prefix, which is also indicated
by the underline (_) under the IPv6 address. If no address is acquired, the field displays Not Available.
6. In the Login field, enter the login information for the ISP connection.
This is usually the name that you use in your email address. For example, if your main mail account is
JerAB@ISP.com, you would type JerAB in this field. Some ISPs (like Mindspring, Earthlink, and T-DSL)
require that you use your full email address when you log in. If your ISP requires your full email address,
type it in this field.
Manage the Internet Settings Manually
77
AC1200 WiFi VDSL/ADSL Modem Router Model D6220
