4. Select ADVANCED > Setup > WAN Setup.
The WAN Setup page displays.
5. To disable the SIP ALG, select the Disable SIP ALG check box.
The SIP ALG is enabled by default.
6. Click the Apply button.
Your settings are saved.
Manage IGMP Proxying
IGMP proxying allows a computer on the local area network (LAN) to receive the multicast traffic it is interested
in from the Internet. If you do not need this feature, leave it disabled, which is the default setting.
To enable IGMP proxying:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Setup > WAN Setup.
The WAN Setup page displays.
5. Clear the Disable IGMP Proxying check box.
By default, the Disable IGMP Proxying check box is selected and IGMP proxying is disabled.
6. Click the Apply button.
Your settings are saved.
Manage the Modem Routers’s LAN IP Address Settings
The modem router is preconfigured to use private IP addresses on the LAN side and to act as a DHCP
server. The modem router’s default LAN IP configuration is as follows:
• LAN IP address. 192.168.0.1 (This is the same as www.routerlogin.net and www.routerlogin.com.)
• Subnet mask. 255.255.255.0
These addresses are part of the designated private address range for use in private networks and are
suitable for most applications.The IP address and subnet mask identify which addresses are local to a
specific device and which must be reached through a gateway or modem router.You might want to change
Manage the WAN and LAN Network Settings
182
AC1200 WiFi VDSL/ADSL Modem Router Model D6220
