The rule is saved in the QoS Priority Rule list.

Set Up QoS for a MAC Address

You can create a QoS policy rule for traffic from a MAC address of a device on the LAN.

To create a QoS policy rule for traffic from a specific MAC address:

1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.

2. Enter http://www.routerlogin.net.

A login window opens.

3. Enter the modem router user name and password.

The user name is admin.The default password is password.The user name and password are

case-sensitive.

The BASIC Home page displays.

4. Select ADVANCED > Setup > QoS Setup.

Optimize Performance

128
