NETGEAR D6220 User Manual

Use the Reset Button
CAUTION:
This process erases all settings that you configured in the modem router.
To reset the modem router to factory default settings:
1. On the back of the modem router, locate the recessed Reset button.
2. Using a straightened paper clip, press and hold the Reset button for at least five seconds.
3. Release the Reset button.
The Power LED starts blinking amber and the configuration is reset to factory default settings.When
the reset is complete, the modem router reboots. This process takes about two minutes.
WARNING:
To avoid the risk of corrupting the firmware, do not interrupt the reset. For
example, if you are connected to the modem router’s web page, do not close
the browser, click a link, or load a new page. Do not turn off the modem router.
Wait until the modem router finishes restarting and the Power LED turns solid
green.
Erase the Settings
CAUTION:
This process erases all settings that you configured in the modem router.
To erase the settings:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
Manage the Modem Router and Monitor the Traffic
199
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

NETGEAR D6220 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Security algorithms	WPA, WPA2, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Routing protocols	IP
Antennas quantity	2
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	182 mm
Width	240 mm
Height	41 mm
Weight	341 g
