NETGEAR D6220 User Manual

7. In the Password field, enter the password for the ISP connection.
8. In the Service Name (If Required) field, enter a service name.
If your ISP did not provide a service name, leave this field blank.
The default setting of the Connection Mode menu is Always On to provide a steady
IPv6 connection.The modem router never terminates the connection. If the connection
is terminated, for example, when the modem is turned off, the modem router attempts
to reestablish the connection immediately after the PPPoE connection becomes
available again.
Note
9. Select an IPv6 Domain Name Server (DNS) Address radio button:
• Get Automatically from ISP.Your ISP uses DHCP to assign your DNS servers.Your ISP
automatically assigns this address.
• Use These DNS Servers. If you know that your ISP requires specific servers, select this option.
Enter the IP address of your ISP’s primary DNS server. If a secondary DNS server address is
available, enter it also.
10. Select an IP Address Assignment radio button:
• Use DHCP Server. This method passes more information to LAN devices but some IPv6 systems
might not support the DHCv6 client function.
• Auto Config. This is the default setting.
This setting specifies how the modem router assigns IPv6 addresses to the devices on your home
network (the LAN).
11. (Optional) Select the Use This Interface ID check box and specify the interface ID to be used for the
IPv6 address of the modem router’s LAN interface.
If you do not specify an ID here, the modem router generates one automatically from its MAC address.
12. Click the Apply button.
Your settings are saved.
Use Auto Config for an IPv6 Internet Connection
To set up an IPv6 Internet connection through autoconfiguration:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Advanced Setup > IPv6.
The Basic Settings page displays.
Manage the Internet Settings Manually
78
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

NETGEAR D6220 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Security algorithms	WPA, WPA2, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Routing protocols	IP
Antennas quantity	2
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	182 mm
Width	240 mm
Height	41 mm
Weight	341 g
