NETGEAR D6220 User Manual

(Continued)
DescriptionField
DHCP Options
Enter the vendor class identifier (VCI) string, as indicated by your ISP.
This field is required for some ISPs only. If your ISP did not provide you with a VCI string,
leave this field blank.
Vendor Class Identifier String
(option 60)
Enter the client identifier (client ID) string, as indicated by your ISP.
This field is required for some ISPs only. If your ISP did not provide you with a client ID
string, leave this field blank.
Client Identifier String (option
61)
13. Click the Apply button.
Your settings are saved.
14. Click the Test button to test your Internet connection.
If the NETGEAR website does not display within one minute, see Troubleshoot the Internet Connection
on page 254.
Specify an ADSL Connection With a Login and PPPoA or PPPoE
Service
If you want to manually configure the ADSL connection settings, use the information that your ISP gave you
to log in and connect to your Internet service. If you cannot find this information, contact your ISP. Entering
incorrect information might prevent the modem router from connecting to the Internet.
If your ISP supports two virtual interfaces (one Internet virtual interface and one IPTV
virtual interface), before you specify the settings for the IPTV interface, first use the
following procedure to specify the settings for the Internet interface. Then repeat the
procedure to specify the settings for the IPTV interface.While doing so, follow the
directions that your ISP gave you.
Note
To view or specify the settings for an ADSL Internet connection that requires a login and
uses a PPPoE or PPPoA service:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
Manage the Internet Settings Manually
46
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

NETGEAR D6220 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Security algorithms	WPA, WPA2, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Routing protocols	IP
Antennas quantity	2
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	182 mm
Width	240 mm
Height	41 mm
Weight	341 g
