The BASIC Home page displays.
4. Select ADVANCED > ADVANCED Home.
The information onscreen uses the following color coding:
•
A green flag indicates that the cable connection or Internet connection is fine and no problems
exist. For a WiFi network, the network is enabled and secured.
•
A red X indicates that configuration problems exist for the cable connection or Internet connection
or the connection is down. For a WiFi network, the network is disabled or down.
•
An amber exclamation mark indicates that the cable port or Internet port is configured but cannot
get an Internet connection (for example, because the cable is disconnected), that a WiFi network
is enabled but unprotected, or that another situation that requires your attention occurred.
The following table describes the fields of the six panes on the ADVANCED Home page.
DescriptionField
Router Information
The modem router model.Hardware Version
The version of the modem router firmware. If you upgrade the firmware on the
modem router, the version changes.
Firmware Version
Manage the Modem Router and Monitor the Traffic
202
AC1200 WiFi VDSL/ADSL Modem Router Model D6220
