NETGEAR D6220 User Manual

The following figure shows the settings that display when you configure an ADSL connection with a
login and PPPoE service.
12. Enter the ADSL settings as described in the following table.
DescriptionField
Select LLC-BASED or VC-BASED, as indicated by your ISP.
The multiplexing method can be either virtual circuit (VC) based or logical link control
(LLC) based.
Multiplexing Method
Enter a number between 0 and 255 for the virtual circuit number for the virtual path
identifier (VPI), as indicated by your ISP.
If your ISP did not provide you with a VPI setting, leave the default setting, which depends
on the selected ISP. The VPI might be required not only for a VC-based connection but
also for an LLC-based connection.
VPI
Manage the Internet Settings Manually
48
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

NETGEAR D6220 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Security algorithms	WPA, WPA2, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Routing protocols	IP
Antennas quantity	2
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	182 mm
Width	240 mm
Height	41 mm
Weight	341 g
