NETGEAR D6220 User Manual

If your ISP supports two virtual interfaces (one Internet virtual interface and one IPTV
virtual interface), before you specify the settings for the IPTV interface, first use the
following procedure to specify the settings for the Internet interface. Then repeat the
procedure to specify the settings for the IPTV interface.While doing so, follow the
directions that your ISP gave you.
Note
To view or specify the settings for a cable Internet connection that does not require a login:
1. Launch a web browser from a WiFi-enabled computer or mobile device that is connected to the network.
2. Enter http://www.routerlogin.net.
A login window opens.
3. Enter the modem router user name and password.
The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Setup > WAN Setup.
The WAN Setup page displays.
5. From the WAN Preference menu, select Must use Ethernet WAN.
By default, the menu selection is Must use DSL WAN.
6. Click the Apply button.
Your settings are saved and the modem router restarts.
If you use a WiFi-enabled computer or mobile device to connect to the modem router,
you might need to log in again.
Note
7. Select BASIC > Internet.
The Internet Setup page displays.
8. From the Select Country menu, select the country in which you use the modem router.
The Select Country menu is not available in all countries and might be masked out.
9. From the Select Internet Service Provider menu, select the Internet service provider (ISP) that you
are using.
If your ISP is not in the menu, select Other.
10. From the menu above the Enable This Interface check box, select the virtual interface that you are
configuring.
• Internet. In all situations, the Internet virtual interface is the one that you must configure first.The
IPTV virtual interface applies only to a few ISPs. In most situations you can ignore the IPTV virtual
interface.
• IPTV. For some ISPs, you must configure the IPTV virtual interface in addition to the Internet virtual
interface. However, first specify the settings for the Internet virtual interface (which is the default
interface) before you repeat the procedure to specify the settings for the IPTV virtual interface.
Manage the Internet Settings Manually
61
AC1200 WiFi VDSL/ADSL Modem Router Model D6220

NETGEAR D6220 Specifications

General

DSL WAN	-
Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	900 Mbit/s
Product type	Tabletop router
Product color	Black
Security algorithms	WPA, WPA2, WPA2-PSK
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11ac
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Power source type	AC
Routing protocols	IP
Antennas quantity	2
Cables included	LAN (RJ-45), Phone (RJ-11)

Weight and Dimensions

Depth	182 mm
Width	240 mm
Height	41 mm
Weight	341 g
