Configure Switching Information
200
M4100 Series Managed Switch
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Switching
LAG LAG Membership.
8. Use LAG ID to select the identification of the LAG.
9. Use LAG Name to enter the name you want assigned to the LAG.
You can enter any string
of up to 15 alphanumeric characters. A valid name must be specified for you to create the
LAG.
10. Use LAG Description to enter the description string to be attached to a LAG.
It can be up to 64 characters in length.
11. In the Admin Mode list, select Enable or Disable.
When the LAG is disabled, no traffic flows and LACPDUs are dropped, but the links that
form the LAG are not released.
The factory default is enabled.
12. Use Link Trap to specify whether a trap is sent when link status changes.
The factory default is enable, which causes the trap to be sent.
13. Use STP Mode to enable or disable the Spanning
Tree Protocol administrative mode
associated with the LAG.
The possible values are as follows:
• Disable. Spanning tree is disabled for this LAG.
• Enable. Spanning tree is enabled for this LAG.
14. Use Static Mode to select Enable or Disable.
