Manage Device Security
310
M4100 Series Managed Switch
The following table describes the nonconfigurable information displayed on the screen.
Table 84. Client summary
Field Description
Port The port to be displayed.
User Name This field displays the user name representing the identity of the
supplicant device.
Supplicant Mac Address This field displays supplicant's device MAC address.
Session Time This field displays the time since the supplicant as logged, in seconds.
Filter ID This field displays policy filter ID assigned by the authenticator to the
supplicant device.
Vlan ID This field displays VLAN ID assigned by the authenticator to the
supplicant device.
Vlan Assigned This field displays reason for the VLAN ID assigned by the
authenticator to the supplicant device.
Session Timeout This field displays session timeout set by the RADIUS server to the
supplicant device.
Termination Action This field displays termination action set by the RADIUS server to the
supplicant device.
Traffic Control
You can configure MAC filters, storm control, port security, and protected port settings. To
display the screen, select Security
Traffic Control.
Configure MAC Filter Settings
You can create MAC filters that limit the traffic allowed into and out of specified ports on the
system.
To configure MAC filter settings:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
