Monitoring the System
386
M4100 Series Managed Switch
The default port is 514.
10. In the IP Address Type list, select one of the following:
• IPv4
• IPv6
• DNS
11. In the Host Address field, type the address of the host configured for syslog.
12. In the Port field, type the port number on the host to which syslog messages are sent.
The default port is 514.
13. In the Severity Filter list, select a severity level.
A log records messages equal to or above a configured severity threshold. These
severity levels are available:
• Emergency (0). The system is unusable
• Alert (1). Action must be taken immediately
• Critical (2). Critical conditions
• Error (3). Error conditions
• Warning (4). Warning conditions
• Notice (5). Normal but significant conditions
• Informational (6). Informational messages
• Debug (7). Debug-level messages
View Trap Logs
Note: You can save the trap logs as a file by using System Utilities >
Upload File from Switch.
To view trap logs:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
