Configure Switching Information
182
M4100 Series Managed Switch
The following table describes the nonconfigurable information displayed on the screen.
Table 55. MLD Snooping Querier VLAN Configuration
Field Description
Operational State Specifies the operational state of the MLD snooping querier on a VLAN.
It can be in any of the following states:
• Querier:
The snooping switch is the querier in the VLAN. The
snooping switch sends out periodic queries with a time interval
equal to the configured querier query interval. If the snooping
switch sees a better querier in the VLAN, it moves to non-querier
mode.
• Non-Querier:
The snooping switch is in non-querier mode in the
VLAN. If the querier expiry interval timer is expired, the snooping
switch moves into querier mode.
• Disabled:
The snooping Querier is not operational on the VLAN.
The snooping querier moves to disabled mode when MLD
snooping is not operational on the VLAN or when the querier
address is not configured or the network management address is
also not configured.
Operational Version Displays the operational MLD protocol version of the querier.
Last Querier Address Displays the IP address of the last querier from which a query was
snooped on the VLAN.
Last Querier Version Displays the MLD protocol version of the last querier from which a
query was snooped on the VLAN.
Operational Max Response Time Displays maximum response time to be used in the queries that are
sent by the snooping querier
.
Configure MVR
 To configure MVR:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
