NETGEAR M4100 Series User Manual

Configure System Information
73
M4100 Series Managed Switch
The following table describes the DHCP L2 Relay Interface Statistics fields.
Table 21. DHCP L2 Relay Interface Statistics
Field Description
Interface The interface from which the DHCP messages are received.
UntrustedServerMsgsWithOpt82 The number of DHCP messages with option82 received from an
untrusted server
.
UntrustedClientMsgsWithOpt82 The number of DHCP messages with option82 received from an
untrusted client.
TrustedServerMsgsWithoutOpt82 The number of DHCP messages without option82 received from a
trusted server
.
TrustedClientMsgsWithoutOpt82 The number of DHCP messages without option82 received from a
trusted client.
Configure UDP Relay Global Settings
 To configure the UDP Relay global settings:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
