Manage Device Security
309
M4100 Series Managed Switch
View the Client Summary
To view the client summary:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Security
Port Authentication Advanced Client Summary.
Session Termination Action This field displays termination action set by the RADIUS server for the
selected port. This field is displayed only when the port control mode of
the selected port is not MAC-based. Possible values are as follows:
• Default
• Reauthenticate
If the termination action is default then at the end of the session, the
client details are initialized. Otherwise, re-authentication is attempted.
Port Status This field shows the authorization status of the specified port. The
possible values are
Authorized, Unauthorized, and N/A. If the port is in
detached state, the value is N/A because the port cannot participate in
port access control.
Table 83. Port summary
Field Description
