Manage Device Security
308
M4100 Series Managed Switch
Authenticator PAE State This field displays the current state of the authenticator PAE state
machine. Possible values are as follows:
• Initialize
• Disconnected
• Connecting
• Authenticating
• Authenticated
• Aborting
• Held
• ForceAuthorized
• ForceUnauthorized.
Backend State This field displays the current state of the backend authentication state
machine. Possible values are as follows:
• Request
• Response
• Success
• Fail
• Timeout
• Initialize
• Idle
Vlan Assigned This field displays the VLAN ID assigned to the selected interface by
the authenticator. This field is displayed only when the port control
mode of the selected interface is not MAC-based. This field is not
configurable.
Vlan Assigned Reason This field displays reason for the VLAN ID assigned by the
authenticator to the selected interface. This field is displayed only when
the port control mode of the selected interface is not MAC-based. This
field is not configurable. Possible values are as follows:
• Radius
• Unauth
• Default
• Not Assigned
Key Transmission Enabled This field displays if key transmission is enabled on the selected port.
This is not a configurable field. The possible values are 'true' and
'false'. If the value is 'false' key transmission does not occur. Otherwise,
key transmission is supported on the selected port.
Session Timeout This field displays session rimeout set by the Radius server for the
selected port. This field is displayed only when the port control mode of
the selected port is not MAC-based.
Table 83. Port summary
Field Description
