NETGEAR M4100 Series User Manual

Configure Quality of Service
258
M4100 Series Managed Switch
3. Launch a web browser.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select QoS
 DiffServ  Advanced  Service Interface Configuration.
8. Use Interface to select the interface for the DiffServer service.
9. In the a Policy Name list, select a name.
This list includes all the policy names. This field is not shown for Read/Write users where
inbound service policy attachment is not supported by the platform.
The following table describes the nonconfigurable information displayed on the screen.
Table 75. Service Interface Configuration
Field Description
Direction Shows that the traffic direction of this service interface is In.
Operational Status Shows the operational status of this service interface, either Up or
Down.
View Service Statistics
You can view class-oriented statistical information for the policy, which is specified by the
interface and direction. The Member Classes menu is populated on the basis of the specified

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
