NETGEAR M4100 Series User Manual

Configure Switching Information
172
M4100 Series Managed Switch
The querier expiry interval must be a value in the range of 60 and 300. The default value
is 125.
Table 51. IGMP Snooping Querier Configuration
Field Description
VLAN IDs Enabled For IGMP Snooping Querier Displays VLAN IDs enabled for IGMP snooping
querier
.
IGMP Snooping Querier VLAN Configuration
You can configure IGMP queriers for use with VLANs on the network.
 To configure IGMP queriers for use with VLANs:
1. Prepare your computer with a static IP address in the 169.254.100.0 subnet, for
example, 169.254.100.201.
2. Connect an Ethernet cable from an Ethernet port on your computer to an Ethernet port on
the switch.
3. Launch a web browser
.
4. Enter the IP address of the switch in the web browser address field.
The default IP address of the switch is 169.254.100.100.
The Login screen displays.
5. Enter the user name and password.
The default admin user name is admin and the default admin password is blank, that is,
do not enter a password.
6. Click the Login button.
The web management interface menu displays.
7. Select Switching
 Multicast  IGMP Snooping  Querier VLAN Configuration.
8. To create a new VLAN ID for IGMP snooping, select New Entry from the VLAN ID field and
complete the following fields.
You can also set pre-configurable snooping querier parameters.
