NETGEAR M4100 Series User Manual

Configure Switching Information
173
M4100 Series Managed Switch
• VLAN ID. Specifies the VLAN ID for which the IGMP snooping querier is to be
enabled.
• Querier Election Participate Mode. Enable or disable querier participate mode.
• Disabled. Upon seeing another querier of the same version in the VLAN, the
snooping querier moves to the non-querier state.
• Enabled.
The snooping querier participates in querier election, in which the least
IP address operates as the querier in that VLAN. The other querier moves to
non-querier state.
• Snooping Querier VLAN
Address. Specify the snooping querier IP address to be
used as the source address in periodic IGMP queries sent on the specified VLAN.
9. Click the APPL
Y button.
The new settings are applied to the switch. Configuration changes take effect
immediately
10. T
o disable snooping querier on a VLAN, select the VLAN ID and click the DELETE button.
11. Click the REFRESH button to update the screen with the latest information from the switch.
The following table describes the nonconfigurable information displayed on the screen.
Table 52. IGMP Snooping Querier VLAN Configuration
Field Description
Operational State Displays the operational state of the IGMP snooping querier on a
VLAN. It can be in any of the following states:
• Querier:
The snooping switch is the querier in the VLAN. The
snooping switch sends out periodic queries with a time interval
equal to the configured querier query interval. If the snooping
switch sees a better querier in the VLAN, it moves to non-querier
mode.
• Non-Querier:
The snooping switch is in non-querier mode in the
VLAN. If the querier expiry interval timer is expired, the snooping
switch moves into querier mode.
• Disabled: Snooping querier is not operational on the VLAN.
The
snooping querier moves to disabled mode when IGMP snooping is
not operational on the VLAN or when the querier address is not
configured or the network management address is also not
configured.
Operational Version Displays the operational IGMP protocol version of the querier.
Last Querier Address Displays the IP address of the last querier from which a query was
snooped on the VLAN.
Last Querier Version Displays the IGMP protocol version of the last querier from which a
query was snooped on the VLAN.
Operational Max Response Time Displays maximum response time to be used in the queries that are
sent by the snooping querier
.

NETGEAR M4100 Series Specifications

General

Model	M4100 Series
Switch Type	Managed
Form Factor	Rack-mountable
Port Configuration	24 or 48 ports
Ethernet Ports	10/100/1000 Mbps
PoE Support	Available on some models (PoE and PoE+)
Layer	Layer 2/Layer 3
Management	Web-based, CLI, SNMP
VLAN Support	Yes
QoS	Yes
Stackable	Yes
Ports	24 or 48
Jumbo Frame Support	Yes
Security Features	ACL, 802.1X, RADIUS, TACACS+
Operating Temperature	0° to 50° C (32° to 122° F)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Power Supply	Internal power supply
